Features/Benefits Specifications Project Download
  • LED lamps with patented mirror technology
  • Visibility up to 1 mile
  • Visual indication of arrow modes on controller
  • Low vehicle battery and short circuit condition
  • Auto up/down motor function
  • Working modes: 25bulls-5 flashing modes, 7 sequential modes 15bulls-5 flashing modes, 2 sequential modes
  • View distance: >1000m
size 1524*760*70mm 1200*600*55mm
Power supply battery@12VDC solar battery@12VDC solar
Model# NBAB-VIP25/15 NBAB-S25/15 NBAB-VIP25/15 NBAB-S25/15S
Number of bulbs 25/15
LEDs per bulb 9leds
Power consumption Max.9.6w/Min.2w
Lens diameter 85mm
Gross Weight 61kgs 66kgs 37kgs 42kgs
Packing size(cm) 166*89*23 166*89*25 134*73*26 134*70*23
Remote wireless controller
Wired car controller optional optional
Arrow board housing Cold rolled steel
Bracket optional
Auto up/down actuators X X
Solar panel X 10W@12VDC X 10W@12VDC
Rechargeable lithium battery X 13.2ah X 13.2ah
